Steel Louver Doors

Engineered for Ventilation. Built for Strength

Vanguard Steel Louver Doors are designed to provide controlled airflow and ventilation while maintaining security, durability, and aesthetics. Ideal for mechanical rooms, electrical rooms, equipment enclosures, and industrial facilities, these doors ensure proper air circulation without compromising on safety or structural integrity. Available in multiple configurations, Vanguard louver doors are tailored to meet both performance and architectural requirements.

Steel Frames
  • Fabricated from commercial-grade cold rolled steel (ASTM A366) or hot-dip galvanized steel (ASTM A653)
  • Available frame thickness:
    -1.6 mm (14 gauge)
    -2.0 mm (12 gauge)
  • Precision-bent corners with sharp radius for added rigidity and seamless alignment
  • Optional frame anchoring systems available (masonry, drywall, etc.)
Steel Shutters with Louvers
  • 46 mm thick door leaf with louver cutouts as required sizes.
  • Fabricated using ASTM A366 cold rolled steel or ASTM A526 galvanized steel
  • Available in 1.0 mm or 1.2 mm thickness
  • Vertical edges interlocked with 1.2 mm deep top and bottom end channels
  • Louvered panels integrated into the door shutter, with fixed blades for free airflow
  • Blade type:
    -Z-type or inverted Y-type blades
    -Weather-resistant or vision-proof options available
  • Free Air Area: Up to 50% depending on design
  • Optional features: insect mesh
  • Available Sizes:
  • Single Door: Up to 1200 mm (W) × 2400 mm (H)
  • Double Door: Up to 2400 mm (W) × 2400 mm (H)
  • Custom sizes and configurations available on request
Ironmongery
  • Supplied as per BS or ANSI standards
  • Pre-cut concealed openings for hardware installation
  • Standard door set includes:
    - Stainless Steel Butt Hinges
    -Mortise Lockset
    -Euro Profile Double Cylinder
    -Lever Handle or D-Pull Handle
    -Door Closer
    -Door Stopper
  • Ironmongery provided separately along with installation guidelines
Finish & Colour Options
  • Powder-coated finish applied via electrostatic process and oven-baked for durability
  • Standard coating thickness: 70–80 microns (customizable up to 150 microns)
  • Available in textured or smooth finish
  • Full RAL colour range offered for architectural flexibility
Applications
  • Plant rooms and electrical panels
  • Generator and HVAC enclosures
  • Warehouses and industrial zones
  • Pump rooms and water treatment facilities
  • Transformer yards and substations
  • General-purpose ventilated spaces
Why Choose Vanguard Louver Doors?
  • Custom-engineered for optimal airflow and security
  • High durability, corrosion resistance, and long service life
  • Compliance with ventilation, fire, and safety regulations
  • Wide variety of louver types and air performance configurations
  • Prompt delivery and technical support
